EVGA GeForce GTX 1080 ACX 3.0 EVGA GeForce GTX 1080 ACX 3.0 Card Precision XOC VR Ready

The EVGA GeForce GTX 1080 featuring EVGA ACX 3.0 cooling has arrived. This new graphics card features NVIDIA's new "Pascal" graphics processor which is the most advanced gaming GPU ever created. This breakthrough GPU delivers industry-leading performance, innovative new gaming technologies, and immersive, next-gen VR.

These cards also feature EVGA ACX 3.0 cooling technology. EVGA ACX 3.0 once again brings new and exciting features to the award winning EVGA ACX cooling technology. SHP 3.0 gives increased heatpipes and copper contact area for cooler operation, and optimized fan curve for even quieter gaming. Of course, ACX 3.0 coolers also feature optimized swept fan blades, double ball bearings and an extreme low power motor, delivering more air flow with less power, unlocking additional power for the GPU. Select EVGA ACX 3.0 models will even feature a 10CM fan and RGB LED, allowing complete control over the color from EVGA Precision XOC.

EVGA Precision XOC Unlocks the Power of Pascal

The next generation of EVGA PrecisionX has arrived with EVGA Precision XOC. This new version of Precision is built for the NVIDIA Pascal architecture and combines the best of EVGA Precision and EVGA OC Scanner to give you never before seen overclocking features and built in automatic overclock tuning.

Standard Overclock Mode

Pascal Linear

Pascal Manual

Built In Automatic Tuning

Define your game with EVGA Precision XOC
Introducing EVGA ACX 3.0 ACX 3.0 Cooling
Adjustable RGB LED

* Available on select models

An RGB LED that allows complete control of the color through EVGA Precision XOC.

EVGA ACX 3.0 fans use double ball bearings, which offer 4X longer lifespan than the sleeve bearing fans used by competitors. The oil that is used in sleeve bearing fans makes them vulnerable and prone to failure after time when the oil dries up. Upgrade to EVGA ACX 3.0 and your card will go the distance!

Did you know that power consumption of the fans can directly affect your maximum overclock? The maximum “power target” takes into account the fan power consumption, meaning the lower the power consumption from the fan, the more power available for the card. EVGA ACX 3.0 coolers use more than 4X lower power than competitors allowing for better and more stable overclocks.

Above test conducted with both fans set to the same acoustic level.

8GB of high performance memory running at extreme Clockspeeds giving you access to higher texture qualities in games and improved 4K gaming performance. Did we mention that this memory is running at an extreme 10,000MHz out of the box??!!

Looking for something even cooler? Achieve gaming bliss when paired up with an EVGA HYBRID or HYDRO water cooler.

NOW AVAILABLE

EVGA GeForce GTX 1080


08G-P4-6299
EVGA GeForce GTX 1080 HYDRO COPPER

Core

  • 2560 CUDA Cores
  • Base Clock: 1721 MHz
  • Boost Clock: 1860 MHz
  • Bus: PCIe 3.0
  • 2-way SLI Ready

Memory

  • Memory Detail: 8192 MB GDDR5X
  • Memory Bit Width: 256 Bit
  • Memory Clock: 10000 MHz
  • Memory Speed: 0.2 ns
  • Memory Bandwidth: 320 GB/s

Key Features

  • EVGA Double BIOS
  • Simultaneous Multi-Projection
  • VR Ready
  • NVIDIA® Ansel
  • NVIDIA SLI w/ HB Bridge Support
  • NVIDIA G-SYNC
  • NVIDIA GameStream
  • NVIDIA GPU Boost 3.0
  • Microsoft DirectX 12 API
  • Vulkan API
  • OpenGL 4.6 Support
  • PCI Express 3.0
  • Max Digital Resolution - 7680x4320
  • HDMI 2.0b, DisplayPort 1.4 and Dual-Link DVI
  • Built for EVGA Precision XOC
  • 10 Phase Power Design
  • Adjustable RGB LED

08G-P4-6288
EVGA GeForce GTX 1080 FTW HYBRID

Core

  • 2560 CUDA Cores
  • Base Clock: 1721 MHz
  • Boost Clock: 1860 MHz
  • Bus: PCIe 3.0
  • 2-way SLI Ready

Memory

  • Memory Detail: 8192 MB GDDR5X
  • Memory Bit Width: 256 Bit
  • Memory Clock: 10000 MHz
  • Memory Speed: 0.2 ns
  • Memory Bandwidth: 320 GB/s

Key Features

  • EVGA Double BIOS
  • Simultaneous Multi-Projection
  • VR Ready
  • NVIDIA® Ansel
  • NVIDIA SLI w/ HB Bridge Support
  • NVIDIA G-SYNC
  • NVIDIA GameStream
  • NVIDIA GPU Boost 3.0
  • Microsoft DirectX 12 API
  • Vulkan API
  • OpenGL 4.6 Support
  • PCI Express 3.0
  • Max Digital Resolution - 7680x4320
  • HDMI 2.0b, DisplayPort 1.4 and Dual-Link DVI
  • Built for EVGA Precision XOC
  • 10 Phase Power Design
  • Adjustable RGB LED
  • Hybrid "All-in-One" Watercooler

08G-P4-6188
EVGA GeForce GTX 1080 HYBRID

Core

  • 2560 CUDA Cores
  • Base Clock: 1708 MHz
  • Boost Clock: 1847 MHz
  • Bus: PCIe 3.0
  • 2-way SLI Ready

Memory

  • Memory Detail: 8192 MB GDDR5X
  • Memory Bit Width: 256 Bit
  • Memory Clock: 10010 MHz
  • Memory Speed: 0.2 ns
  • Memory Bandwidth: 320 GB/s

Key Features

  • Simultaneous Multi-Projection
  • VR Ready
  • NVIDIA® Ansel
  • NVIDIA SLI w/ HB Bridge Support
  • NVIDIA G-SYNC
  • NVIDIA GameStream
  • NVIDIA GPU Boost 3.0
  • Microsoft DirectX 12 API
  • Vulkan API
  • OpenGL 4.6 Support
  • PCI Express 3.0
  • Max Digital Resolution - 7680x4320
  • HDMI 2.0b, DisplayPort 1.4 and Dual-Link DVI
  • Built for EVGA Precision XOC
  • Hybrid "All-in-One" Watercooler

08G-P4-6386
EVGA GeForce GTX 1080 CLASSIFIED GAMING ACX 3.0

Core

  • 2560 CUDA Cores
  • Base Clock: 1721 MHz
  • Boost Clock: 1860 MHz
  • Bus: PCIe 3.0
  • 2-way SLI Ready

Memory

  • Memory Detail: 8192 MB GDDR5X
  • Memory Bit Width: 256 Bit
  • Memory Clock: 10000 MHz
  • Memory Speed: 0.2 ns
  • Memory Bandwidth: 320 GB/s

Key Features

  • EVGA Double BIOS
  • Simultaneous Multi-Projection
  • VR Ready
  • NVIDIA® Ansel
  • NVIDIA SLI w/ HB Bridge Support
  • NVIDIA G-SYNC
  • NVIDIA GameStream
  • NVIDIA GPU Boost 3.0
  • Microsoft DirectX 12 API
  • Vulkan API
  • OpenGL 4.6 Support
  • PCI Express 3.0
  • Max Digital Resolution - 7680x4320
  • HDMI 2.0b, DisplayPort 1.4 and Dual-Link DVI
  • Built for EVGA Precision XOC
  • EVGA ACX 3.0 Cooling
  • Adjustable RGB LED
  • 14 Phase Power Design

08G-P4-6286
EVGA GeForce GTX 1080 FTW GAMING ACX 3.0

Core

  • 2560 CUDA Cores
  • Base Clock: 1721 MHz
  • Boost Clock: 1860 MHz
  • Bus: PCIe 3.0
  • 2-way SLI Ready

Memory

  • Memory Detail: 8192 MB GDDR5X
  • Memory Bit Width: 256 Bit
  • Memory Clock: 10000 MHz
  • Memory Speed: 0.18 ns
  • Memory Bandwidth: 320 GB/s

Key Features

  • EVGA Double BIOS
  • Simultaneous Multi-Projection
  • VR Ready
  • NVIDIA® Ansel
  • NVIDIA SLI w/ HB Bridge Support
  • NVIDIA G-SYNC
  • NVIDIA GameStream
  • NVIDIA GPU Boost 3.0
  • Microsoft DirectX 12 API
  • Vulkan API
  • OpenGL 4.6 Support
  • PCI Express 3.0
  • Max Digital Resolution - 7680x4320
  • HDMI 2.0b, DisplayPort 1.4 and Dual-Link DVI
  • Built for EVGA Precision XOC
  • EVGA ACX 3.0 Cooling
  • 10 Phase Power Design
  • Adjustable RGB LED

08G-P4-6183
EVGA GeForce GTX 1080 SC GAMING ACX 3.0

Core

  • 2560 CUDA Cores
  • Base Clock: 1708 MHz
  • Boost Clock: 1847 MHz
  • Bus: PCIe 3.0
  • 2-way SLI Ready

Memory

  • Memory Detail: 8192 MB GDDR5X
  • Memory Bit Width: 256 Bit
  • Memory Clock: 10010 MHz
  • Memory Speed: 0.2 ns
  • Memory Bandwidth: 320 GB/s

Key Features

  • Simultaneous Multi-Projection
  • VR Ready
  • NVIDIA® Ansel
  • NVIDIA SLI w/ HB Bridge Support
  • NVIDIA G-SYNC
  • NVIDIA GameStream
  • NVIDIA GPU Boost 3.0
  • Microsoft DirectX 12 API
  • Vulkan API
  • OpenGL 4.6 Support
  • PCI Express 3.0
  • Max Digital Resolution - 7680x4320
  • HDMI 2.0b, DisplayPort 1.4 and Dual-Link DVI
  • Built for EVGA Precision XOC
  • EVGA ACX 3.0 Cooling

08G-P4-6181
EVGA GeForce GTX 1080 ACX 3.0

Core

  • 2560 CUDA Cores
  • Base Clock: 1607 MHz
  • Boost Clock: 1733 MHz
  • Bus: PCIe 3.0
  • 2-way SLI Ready

Memory

  • Memory Detail: 8192 MB GDDR5X
  • Memory Bit Width: 256 Bit
  • Memory Clock: 10010 MHz
  • Memory Speed: 0.2 ns
  • Memory Bandwidth: 320 GB/s

Key Features

  • Simultaneous Multi-Projection
  • VR Ready
  • NVIDIA® Ansel
  • NVIDIA SLI w/ HB Bridge Support
  • NVIDIA G-SYNC
  • NVIDIA GameStream
  • NVIDIA GPU Boost 3.0
  • Microsoft DirectX 12 API
  • Vulkan API
  • OpenGL 4.6 Support
  • PCI Express 3.0
  • Max Digital Resolution - 7680x4320
  • HDMI 2.0b, DisplayPort 1.4 and Dual-Link DVI
  • Built for EVGA Precision XOC

08G-P4-6180
EVGA GeForce GTX 1080 FOUNDERS EDITION

Core

  • 2560 CUDA Cores
  • Base Clock: 1607 MHz
  • Boost Clock: 1733 MHz
  • Bus: PCIe 3.0
  • 2-way SLI Ready

Memory

  • Memory Detail: 8192 MB GDDR5X
  • Memory Bit Width: 256 Bit
  • Memory Clock: 10010 MHz
  • Memory Speed: 0.2 ns
  • Memory Bandwidth: 320 GB/s

Key Features

  • Simultaneous Multi-Projection
  • VR Ready
  • NVIDIA® Ansel
  • NVIDIA SLI w/ HB Bridge Support
  • NVIDIA G-SYNC
  • NVIDIA GameStream
  • NVIDIA GPU Boost 3.0
  • Microsoft DirectX 12 API
  • Vulkan API
  • OpenGL 4.6 Support
  • PCI Express 3.0
  • Max Digital Resolution - 7680x4320
  • HDMI 2.0b, DisplayPort 1.4 and Dual-Link DVI
  • Built for EVGA Precision XOC

EVGA GeForce GTX 1080 Comparison Chart

EVGA GRAPHICS CARD PART NO. BASE / BOOST
CLOCK
LED BIOS COOLER POWER
TYPE
PERFORMANCE BACKPLATE
EVGA GeForce GTX 1080 Hydro Copper 08G-P4-6299-KR 1721/1860 RGB 2 Waterblock 10 + 2 Best Yes
EVGA GeForce GTX 1080 FTW Hybrid 08G-P4-6288-KR 1721/1860 RGB 2 Hybrid 10 + 2 Great Yes
EVGA GeForce GTX 1080 Hybrid 08G-P4-6188-KR 1708/1847 YES (WHITE) 2 Hybrid 5 + 1 Great Yes
EVGA GeForce GTX 1080 Classified ACX 3.0 08G-P4-6386-KR 1721/1860 RGB 2 ACX 3.0 14 + 3 Great Yes
EVGA GeForce GTX 1080 FTW ACX 3.0 08G-P4-6286-KR 1721/1860 RGB 2 ACX 3.0 10 + 2 Great Yes
EVGA GeForce GTX 1080 SC ACX 3.0 08G-P4-6183-KR 1708/1847 YES (WHITE) 1 ACX 3.0 5 + 1 Better Yes
EVGA GeForce GTX 1080 ACX 3.0 08G-P4-6181-KR 1607/1733 YES (WHITE) 1 ACX 3.0 5 + 1 Good Yes
EVGA GeForce GTX 1080 Founders Ed. 08G-P4-6180-KR 1607/1733 YES (GREEN) 1 Single Fan 5 + 1 Good Yes
