Ready for 4th Generation Intel Core Processors (C6/C7 Idle Mode)
The EVGA SuperNOVA 1000 G2 has arrived! This power supply is 80 Plus Gold Rated, offers 1000W of continuous power, exceptional efficiency and is fully modular. Not to mention, a first class 10 Year EVGA Warranty. Designed with enthusiast needs in mind the EVGA SuperNOVA 1000 G2 power supply is the best choice to power this and next generation enthusiast computers. Take your system to the next level and power up with the EVGA SuperNOVA 1000 G2!
NOTE: For power supplies purchased in Europe, a European style power cable will be provided.
Learn more here
Cable Length
|
1x 600mm |
|
2x 750mm |
|
2x 750mm, 900mm 4x 750mm |
|
2x 550mm, 650mm, 750mm 2x 550mm, 650mm |
|
1x 550mm, 650mm, 750mm 1x 550mm,650mm (f) |
|
1x 100mm |
|
1x 1500mm |
|
Full |
Connector Quantity
|
1x |
|
2x 8pin (4+4) |
|
6x 8pin (6+2), 2x 6pin |
|
10x |
|
5x |
|
1x |
Power Specs
|
100 - 240 VAC, 15A, 50 - 60 Hz |
|
+3.3V |
+5V |
+12V |
+5Vsb |
-12V |
|
24A |
24A |
83.3A |
3A |
0.5A |
|
83A |
|
120W |
999.6W |
15W |
6W |
|
1000W @ +50C |
Additional Details
|
0° to 50° C |
|
100% |
|
Yes |
|
100,000 Hours |
|
7 lbs |
|
85mm (H) x 0mm (W) x 200mm (L) |
TUV, CB, CE, FCC, RCM, cTUVus, WEEE, RoHS
Compliance with ErP Lot 6 2013 Requirement
|
|
140mm
Double Ball Bearing |
Product Warranty
This product comes with a 10 year limited warranty with registration.
EVGA offers several warranty solutions for our customers to choose from. Please refer to the suffix of the part number and our Warranty Terms for details.
Unbeatable EVGA 10 Year Warranty and unparalleled EVGA Customer Support
80 PLUS Gold certified, with 90% (115VAC) / 92% (220VAC~240VAC) efficiency or higher under typical loads
Highest quality Japanese brand capacitors ensure long-term reliability
Fully Modular to reduce clutter and improve airflow
NVIDIA SLI & AMD Crossfire Ready
Double Ball Bearing fan for exceptional reliability and quiet operation
Heavy-duty protections, including OVP (Over Voltage Protection), UVP (Under Voltage Protection), OCP (Over Current Protection), OPP (Over Power Protection), and SCP (Short Circuit Protection)
Awards of the EVGA SuperNOVA 1000 G2, 80+ GOLD 1000W, Fully Modular, 10 Year Warranty, Includes FREE Power On Self Tester Power Supply 120-G2-1000-X2 (EU) (120-G2-1000-X2)
Im Gegenzug erhält man aber leistungsfähiges, leises und effizientes Netzteil das zudem mit 10 Jahren Garantie aufwarten kann!
Im Gegenzug erhält man aber leistungsfähiges, leises und effizientes Netzteil das zudem mit 10 Jahren Garantie aufwarten kann!
Die Anschlussmöglichkeiten sind für ein 1000W Netzteil hervorragend, die Effizienz übertrifft die 80Plus Gold Effizienzvorschrift bei weitem und das Netzteil verfügt über eine hohe Fertigungs und DC-Output Qualität.
EVGA's second ever submission to this site just happens to be absolutely fantastic. The Supernova G2 1000 watt unit is stable, it's low on ripple, and it's plenty efficient.
EVGA continues their march into the PSU market with an excellent and almost flawless product. The fresh SuperNOVA G2 1000 performs exceptionally well, features a fully modular design with plenty of connectors to power a high-end system, is of a high build quality, and, most importantly, manages to offer all the above at a very good price
In testing, the EVGA SuperNOVA 1000 G2 had excellent voltage regulation. There was little to no voltage drop when the PSU was placed under higher loads.
The connectivity options are amazing for a 1000W PSU and the efficiency surpasses the 80 plus Gold standard with a huge margin. Furthermore this PSU is very well built and the DC output quality is very good.
If you're in the market for a high wattage PSU with impressive specs and performance, this is it!
